| Inombolo yendawo | S290AJ1-LE2 Rev.C2 |
| Uphawu | Innolux |
| Ubungakanani | 28.6 |
| Isicelo | Digital Signage Stre |
| Isigqibo | 1920×540 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 4500:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| umenzi | Innolux |
| igama lemodeli | S290AJ1-LE2 Rev.C2 |
| ubungakanani besikrini | 28.6 inch (1/2 cut of 32.0") |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 1920(RGB)×540 69PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 698.4 × 196.425 (H×V) |
| Ulwandlalo(mm) | 720.8 × 226.3 × 26.8 (H×V×D) |
| indawo ye-bezel(mm) | 702.4 × 200.4 (H×V) |
| unyango | Antiglare (Haze 2.4%), Hard coating (3H) |
| ukukhanya | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 4500 : 1 (Typ.) (TM) |
| i-engile yokujonga | 89/89/89/89 (Typ.)(CR≥10) |
| impendulo | 9.5 (Typ.)(G to G) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | Super MVA, Normally Black, Transmissive |
| ubunzulu bombala | 16.7M 72% NTSC |
| isibane esingasemva | WLED , 50K hours , With LED Driver |
| ubunzima | 2.40/2.59/2.80Kgs (Min./Typ./Max.) |
| esetyenziselwa | Digital Signage Stretched Bar LCD |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (2 ch, 8-bit) , Connector 51 pins |
| unikezelo lombane | 12.0V (Typ.) |
| max. amanqaku | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| S290AJ1-LE1 | Innolux | 29.0 | 1920×540 |
