| Inombolo yendawo | S072WX02 |
| Uphawu | CDTECH |
| Ubungakanani | 7.2 |
| Isicelo | Automotive Display I |
| Isigqibo | 1280×370 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 400:1 |
| Imibala | 262K |
| Isibane ngasemva | 5S6P |
| Ujongano | Parallel |
| umenzi | CDTECH |
| igama lemodeli | S072WX02 |
| ubungakanani besikrini | 7.2 inch (1/2 cut of 8.0") |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| inombolo pixel | 1280(RGB)×370 187PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 173.76 × 50.23 (H×V) |
| Ulwandlalo(mm) | 186.18 × 67.35 (H×V×D) |
| indawo ye-bezel(mm) | 177.16 × 55.53 (H×V) |
| unyango | - |
| ukukhanya | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 400 : 1 (Typ.) (TM) |
| i-engile yokujonga | 65/65/55/65 (Typ.)(CR≥10) |
| impendulo | 25/25 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | 12 o'clock |
| imo yomsebenzi | TN, Normally White, Transmissive |
| ubunzulu bombala | 262K 51% NTSC |
| isibane esingasemva | 5S6P WLED , 30K hours , No Driver |
| ubunzima | TBD |
| esetyenziselwa | Automotive Display Industrial Outdoor High Brightness Stretched Bar LCD |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| unikezelo lombane | 3.3/12.63/22/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
