| Inombolo yendawo | S050WV49 |
| Uphawu | CDTECH |
| Ubungakanani | 5.0 |
| Isicelo | Automotive Display I |
| Isigqibo | 800×480 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 600:1 |
| Imibala | 16.7M |
| Isibane ngasemva | 6S2P |
| Ujongano | Parallel |
| umenzi | CDTECH |
| igama lemodeli | S050WV49 |
| ubungakanani besikrini | 5.0 inch |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 800(RGB)×480 (WVGA) 188PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 108 × 64.8 (H×V) |
| Ulwandlalo(mm) | 120.7 × 75.8 × 3.2 (H×V×D) |
| indawo ye-bezel(mm) | 110.6 × 67.6 (H×V) |
| unyango | - |
| ukukhanya | 350 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 600 : 1 (Typ.) (TM) |
| i-engile yokujonga | 65/65/55/65 (Typ.)(CR≥10) |
| impendulo | 20/20 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | 12 o'clock |
| imo yomsebenzi | TN, Normally White, Transmissive |
| ubunzulu bombala | 16.7M 50% NTSC |
| isibane esingasemva | 6S2P WLED , 25K hours , No Driver |
| ubunzima | TBD |
| esetyenziselwa | Automotive Display Industrial |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | Parallel RGB (1 ch, 8-bit) , FPC 40 pins |
| unikezelo lombane | 3.3/10.4/16.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
