| Inombolo yendawo | S046WV01 |
| Uphawu | CDTECH |
| Ubungakanani | 4.6 |
| Isicelo | Industrial |
| Isigqibo | 800×320 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 16.7M |
| Isibane ngasemva | 6S2P |
| Ujongano | Parallel |
| uphawu lwephaneli | CDTECH |
| imodeli yephaneli | S046WV01 |
| ubungakanani bephaneli | 4.6" |
| uhlobo lwephaneli | a-Si TFT-LCD, LCM |
| isisombululo | 800(RGB)×320, 188PPI |
| ifomathi ye-pixel | RGB Vertical Stripe |
| indawo yokubonisa | 108(W)×43.2(H) mm |
| ukuvulwa kwe-bezel | 110.6(W)×46.0(H) mm |
| ubungakanani bamagqabantshintshi | 120.7(W)×56.16(H) ×3.3(D) mm |
| umphezulu | - |
| ukuqaqamba | 350 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 500:1 (Typ.) (TM) |
| i-engile yokujonga | 65/65/55/65 (Typ.)(CR≥10) |
| imowudi yokubonisa | TN, Normally White, Transmissive |
| eyona mbono kwi | 12 o'clock |
| ixesha lokuphendula | 20 (Typ.)(Tr+Td) |
| bonisa imibala | 16.7M 50% NTSC |
| uhlobo lwesibane | 6S2P WLED , 25K hours , Without Driver |
| rhoqo | 60Hz |
| isikrini esibanjwayo | Without |
| Ubunzima bephaneli | TBD |
| isicelo | Industrial |
| ujongano lomqondiso | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| igalelo lombane | 3.3V (Typ.)(VDD) |
| okusingqongileyo | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
