PM058OX1


Uphawu
E Ink
Ubungakanani
5.8
Isicelo
PRO
Isigqibo
1280×768
Ukuqamba
CELL
Ukuqaqamba
0
CR
600:1
Imibala
262K
Isibane ngasemva
No B/L
Ujongano
Mini LVDS
In Stock
800
Iinkcukacha

Inombolo yendawo PM058OX1
UphawuE Ink
Ubungakanani5.8
IsiceloPRO
Isigqibo1280×768
UkuqambaCELL
Ukuqaqamba0
CR600:1
Imibala262K
Isibane ngasemvaNo B/L
UjonganoMini LVDS
uphawu lwephaneliPVI
imodeli yephaneliPM058OX1
uhlobo lwephaneli a-Si TFT-LCD , CELL
ubungakanani bephaneli5.8 inch
isisombululo1280(RGB)×768 , WXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo126.72×74.88 mm
ulwandlalo137.488×84.7 mm
umphezulu
ubunzulu beglasi0.60+0.60 mm
transmissivity6.0% (Typ.)(with Polarizer)
umlinganiselo wokuchasana600:1 (Typ.)
bonisa imibala262K (6-bit)
ixesha lokuphendula15/25 (Typ.)(Tr/Td)
i-engile yokujonga50/50/15/35 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
ujongano lomqondisoMini LVDS, 60 pins
igalelo lombane3.3/3.3/12.5/18.0/-6.0V (Typ.)(VCC/VDD1/VDD2/VGG/VEE)
isiceloPRO
Umzekelo woSapho
C-51850NFQJ-LG-ACN Kyocera 5.8 40×2
DMC-40202NY-LY-AZE-BDN Kyocera 5.8 40×2
LA058WQ1-SD01 LG Display 5.8 400×240
LB058WQ1-SD01 LG Display 5.8 400×240
LQ058T5DG02F SHARP 5.8 480×240
LQ058T5DG30 SHARP 5.8 480×240
LQ058T5DR02 SHARP 5.8 480×272
LQ6BW51N SHARP 5.8 480×234
LQ6BW558T SHARP 5.8 480×234
PM058OX1 E Ink 5.8 1280×768
