MT220WW01 V.6

MT220WW01 V.6
MT220WW01 V.6
MT220WW01 V.6 thumb MT220WW01 V.6 thumb
Uphawu
Innolux
Ubungakanani
22.0
Isicelo
DMPC
Isigqibo
1680×1050
Ukuqamba
LCM
Ukuqaqamba
250
CR
1000:1
Imibala
16.7M
Isibane ngasemva
CCFL
Ujongano
LVDS
In Stock
3862
Iinkcukacha

Inombolo yendawo MT220WW01 V.6
UphawuInnolux
Ubungakanani22.0
IsiceloDMPC
Isigqibo1680×1050
UkuqambaLCM
Ukuqaqamba250
CR1000:1
Imibala16.7M
Isibane ngasemvaCCFL
UjonganoLVDS
uphawu lwephaneliINNOLUX
imodeli yephaneliMT220WW01 V.6
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli22.0 inch
isisombululo1680(RGB)×1050 , WSXGA+
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo473.76×296.1 mm
ulwandlalo493.7×320.1×16.7 mm
umphezuluAntiglare (Haze 25%), Hard coating (3H)
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana1000:1 (Typ.)
bonisa imibala16.7M (6-bit + Hi-FRC)
ixesha lokuphendula1.5/3.5 (Typ.)(Tr/Td)
i-engile yokujonga85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane2 pcsCCFLWithout Driver
ujongano lomqondisoLVDS (1 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
