| Inombolo yendawo | M102AWF2 R1 |
| Uphawu | IVO |
| Ubungakanani | 10.3 |
| Isicelo | Automotive Display |
| Isigqibo | 1920×720 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | IVO |
| imodeli | M102AWF2 R1 |
| ubungakanani bediagonal | 10.3 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 1920(RGB)×720 200PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 243.65(H)×91.37(V) mm |
| ulwandlalo mfiliba. | 262.04(H)×110.3(V) ×12.2(D) mm |
| indawo ye-bezel | 245.65(H)×93.66(V) mm |
| unyango | Hard coating (3H) |
| ukukhanya | 800 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1000:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 20 (Typ.)(Tr+Td) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| indlela yokusebenza | IPS, Normally Black, Transmissive |
| umbala inkxaso | 16.7M 72% NTSC |
| umthombo wokukhanya | WLED [8S3P] , 10K hours , W/O Driver |
| ubunzima | 380g (Max.) |
| yenzelwe | Automotive Display |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | LVDS (2 ch, 8-bit) , 50 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 3.0G (29.4 m/s²) |
