| Inombolo yendawo | LS124M5LZ01 |
| Uphawu | Sharp |
| Ubungakanani | 12.4 |
| Isicelo | Automotive Display |
| Isigqibo | 1920×720 |
| Ukuqamba | LCM, Oxide TFT-LCD |
| Ukuqaqamba | |
| CR | 1500:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| umenzi | Sharp |
| igama lemodeli | LS124M5LZ01 |
| ubungakanani besikrini | 12.4 inch |
| uhlobo lwesikrini | LCM, Oxide TFT-LCD |
| inombolo pixel | 1920(RGB)×720 165PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 295.2 × 110.7 (H×V) |
| Ulwandlalo(mm) | 301.3 × 125.7 × 14.85 (H×V×D) |
| indawo ye-bezel(mm) | 296.6 × 112.1 (H×V) |
| unyango | Antiglare, Antireflection |
| ukukhanya | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1500 : 1 (Typ.) (TM) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| impendulo | 12/12 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | New Mode, Normally Black, Transmissive |
| ubunzulu bombala | 16.7M 74% NTSC |
| isibane esingasemva | WLED , 10K hours , With LED Driver |
| ubunzima | 620g (Typ.) |
| esetyenziselwa | Automotive Display |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (2 ch, 8-bit) , Connector 68 pins |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
