LQ121S1DG21A

LQ121S1DG21A
LQ121S1DG21A
LQ121S1DG21A thumb LQ121S1DG21A thumb
Uphawu
SHARP
Ubungakanani
12.1
Isicelo
IA
Isigqibo
800×600
Ukuqamba
LCM
Ukuqaqamba
300
CR
300:1
Imibala
262K
Isibane ngasemva
CCFL
Ujongano
TTL
In Stock
7583
Iinkcukacha

Inombolo yendawo LQ121S1DG21A
UphawuSHARP
Ubungakanani12.1
IsiceloIA
Isigqibo800×600
UkuqambaLCM
Ukuqaqamba300
CR300:1
Imibala262K
Isibane ngasemvaCCFL
UjonganoTTL
uphawu lwephaneliSHARP
imodeli yephaneliLQ121S1DG21A
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli12.1 inch
isisombululo800(RGB)×600 , SVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo246×184.5 mm
ulwandlalo276×209 mm
umphezuluAntiglare (Haze 28%), Hard coating (3H)
ukuqaqamba300 cd/m² (Typ.)
umlinganiselo wokuchasana300:1 (Typ.)
bonisa imibala262K (6-bit)
ixesha lokuphendula15/30 (Typ.)(Tr/Td)
i-engile yokujonga60/60/45/55 (Typ.)(CR≥10)(L/R/U/D)
uhlobo lwesibane2 pcsCCFLWithout Driver
ujongano lomqondisoParallel RGB (1 ch, 6-bit), 31 pins
igalelo lombane3.3/5.0V (Typ.)(VCC)
rohs:
isiceloIA
Umzekelo woSapho
LQ121S1DG41 SHARP 12.1 800×600
LQ121S1DG43 SHARP 12.1 800×600
LQ121S1DG61 SHARP 12.1 800×600
LQ121S1LG41 SHARP 12.1 800×600
LQ121S1LG55 SHARP 12.1 800×600
LQ121S1LG61 SHARP 12.1 800×600
LQ121S1LG72 SHARP 12.1 800×600
LQ121S1LG75 SHARP 12.1 800×600
LQ121S1LG81 SHARP 12.1 800×600
LQ121S1LG84 SHARP 12.1 800×600
