| Inombolo yendawo | LB070WV8-SL02 |
| Uphawu | LG Display |
| Ubungakanani | 7.0 |
| Isicelo | Industrial Automotiv |
| Isigqibo | 800×480 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| umenzi | LG Display |
| igama lemodeli | LB070WV8-SL02 1 Compatible |
| ubungakanani besikrini | 7.0 inch |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| inombolo pixel | 800(RGB)×480 (WVGA) 133PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 152.4 × 91.44 (H×V) |
| Ulwandlalo(mm) | 170 × 106.3 × 10.7 (H×V×D) |
| indawo ye-bezel(mm) | 155.2 × 94.2 (H×V) |
| unyango | Antiglare |
| ukukhanya | 450 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 800 : 1 (Typ.) (TM) |
| i-engile yokujonga | 89/89/89/89 (Min.)(CR≥10) |
| impendulo | 15/10 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | IPS, Normally Black, Transmissive |
| ubunzulu bombala | 16.7M 60% NTSC |
| isibane esingasemva | WLED , 50K hours , With LED Driver |
| ubunzima | 220g (Max.) |
| esetyenziselwa | Industrial Automotive Display Gaming |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (1 ch, 8-bit) , 30 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 80 °C |
