| Inombolo yendawo | KCS3224ASTT-X6 |
| Uphawu | Kyocera |
| Ubungakanani | 5.7 |
| Isicelo | Industrial |
| Isigqibo | 320×240 |
| Ukuqamba | CSTN-LCD , LCM |
| Ukuqaqamba | |
| CR | 25:1 |
| Imibala | Color |
| Isibane ngasemva | - |
| Ujongano | Parallel |
| uphawu | Kyocera |
| ubungakanani bediagonal | 5.7 inch |
| ifomathi ye-pixel | 320(RGB)×240 [QVGA] 70PPI |
| indawo esebenzayo | 115.2(H)×86.4(V) mm |
| ukukhanya | - |
| Jonga indlela | - |
| i-engile yokujonga | 50/50/30/30 (Typ.)(CR≥2) |
| umbala inkxaso | Color |
| ubunzima | - |
| umgangatho wefreyimu | 75Hz |
| uhlobo lojongano | Parallel Data (1ch, 8-bit) Connector |
| ukunikezwa Amandla | 5.0V (Typ.) |
| okusingqongileyo | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| imodeli | KCS3224ASTT-X6 |
| uhlobo | CSTN-LCD , LCM |
| uqwalaselo | RGB Vertical Stripe |
| ulwandlalo mfiliba. | - |
| umlinganiselo wokuchasana | 25:1 (Typ.) (TM) |
| ixesha lokuphendula | 220/110 (Typ.)(Tr/Td) |
| indlela yokusebenza | STN, Normally Black, Transmissive |
| umthombo wokukhanya | |
| yenzelwe | Industrial |
| indawo yokuthintela | Without |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| COM57H5M10XRC | ORTUSTECH | 5.7 | 640×480 |
| EL320.240.36 HB CCB | Lumineq | 5.7 | 320×240 |
| G057VN01 V2 | AUO | 5.7 | 640×480 |
| LM32019T | SHARP | 5.7 | 320×240 |
| LTA057A341F | TOSHIBA | 5.7 | 320×240 |
| TM057QDH01 | Tianma | 5.7 | 640×480 |
| TM057QDHG02 | Tianma | 5.7 | 640×480 |
