HSD190ME12-A10

HSD190ME12-A10
HSD190ME12-A10 thumb
Uphawu
HannStar
Ubungakanani
19.0
Isicelo
DMPC
Isigqibo
1280×1024
Ukuqamba
LCM
Ukuqaqamba
250
CR
700:1
Imibala
16.2M
Isibane ngasemva
CCFL
Ujongano
LVDS
In Stock
8523
Iinkcukacha

Inombolo yendawo HSD190ME12-A10
UphawuHannStar
Ubungakanani19.0
IsiceloDMPC
Isigqibo1280×1024
UkuqambaLCM
Ukuqaqamba250
CR700:1
Imibala16.2M
Isibane ngasemvaCCFL
UjonganoLVDS
uphawu lwephaneliHannStar
imodeli yephaneliHSD190ME12-A10
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli19.0 inch
isisombululo1280(RGB)×1024 , SXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo376.32×301.056 mm
ulwandlalo404.2×330×19.5 mm
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana700:1 (Typ.)
bonisa imibala16.2M (6-bit + FRC)
ixesha lokuphendula2/6 (Typ.)(Tr/Td)
i-engile yokujonga75/75/70/65 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane4 pcsCCFLWithout Driver
ujongano lomqondisoLVDS (2 ch, 8-bit), 30 pins
igalelo lombane5.0V (Typ.)
isiceloDMPC
Umzekelo woSapho
HSD190ME12-A02 HannStar 19.0 1280×1024
HSD190ME12-A10 HannStar 19.0 1280×1024
HSD190ME13-A13 HannStar 19.0 1280×1024
HSD190ME13-D10 HannStar 19.0 1280×1024
HSD190MEN3-A00 HannStar 19.0 1280×1024
HSD190MEN3-A03 HannStar 19.0 1280×1024
HSD190MEN4-A03 HannStar 19.0 1280×1024
HSD190MEN6-A00 HannStar 19.0 1280×1024
HSD190MEN6-A01 HannStar 19.0 1280×1024
HSD190MGW1-B00 HannStar 19.0 1440×900
