| Inombolo yendawo | HSD123KPW2-A10 |
| Uphawu | HannStar |
| Ubungakanani | 12.3 |
| Isicelo | Automotive Display |
| Isigqibo | 1920×720 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 1100:1 |
| Imibala | 16.7M |
| Isibane ngasemva | 11S4P |
| Ujongano | LVDS |
| umenzi | HannStar |
| ubungakanani besikrini | 12.3 inch |
| inombolo pixel | 1920(RGB)×720 167PPI |
| indawo esebenzayo(mm) | 292.032 × 109.512 (H×V) |
| indawo ye-bezel(mm) | 294.8 × 112.1 (H×V) |
| ukukhanya | 850 cd/m² (Typ.) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| umbono omhle kwi | Symmetry |
| ubunzulu bombala | 16.7M 70% NTSC |
| ubunzima | TBD |
| izinga lokuhlaziya | 60Hz |
| uhlobo lomqondiso | LVDS (2 ch, 8-bit) , 50 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| igama lemodeli | HSD123KPW2-A10 |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| ilungiselelo | RGB Vertical Stripe |
| Ulwandlalo(mm) | 308.1 × 130 × 15.6 (H×V×D) |
| unyango | Glare (Haze 0%) |
| umlinganiselo wokuchasana | 1100 : 1 (Typ.) (TM) |
| impendulo | 16/14 (Typ.)(Tr/Td) ms |
| imo yomsebenzi | IPS Pro, Normally Black, Transmissive |
| isibane esingasemva | 11S4P WLED , 30K hours , No Driver |
| esetyenziselwa | Automotive Display |
| isikrini esibanjwayo | Without |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
