| Inombolo yendawo | HSD121KXN1-A10-0299 |
| Uphawu | HannStar |
| Ubungakanani | 12.1 |
| Isicelo | Automotive Display |
| Isigqibo | 1024×768 |
| Ukuqamba | CELL, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 900:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | No |
| Ujongano | LVDS |
| umenzi | HannStar |
| igama lemodeli | HSD121KXN1-A10-0299 |
| ubungakanani besikrini | 12.1 inch |
| uhlobo lwesikrini | CELL, a-Si TFT-LCD |
| inombolo pixel | 1024(RGB)×768 (XGA) 105PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 245.76 × 184.32 (H×V) |
| Ulwandlalo(mm) | 256.18 × 196.9 × 1.27 (H×V×D) |
| indawo ye-bezel(mm) | - |
| unyango | Antiglare, Hard coating (3H) |
| ukukhanya | 0 cd/m² |
| umlinganiselo wokuchasana | 900 : 1 (Typ.) (TM) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| impendulo | 30 (Typ.)(Tr+Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | IPS Pro, Normally Black, Transmissive |
| ubukhulu beglasi | 0.50+0.50 mm |
| transmissivity | - |
| ubunzulu bombala | 262K/16.7M 70% NTSC |
| isibane esingasemva | No B/L , No Driver |
| ubunzima | 160/180g (Typ./Max.) |
| esetyenziselwa | Automotive Display |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (1 ch, 6/8-bit) , Connector 20 pins |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
