| Inombolo yendawo | HSD103JPW2-H10 |
| Uphawu | HannStar |
| Ubungakanani | 10.3 |
| Isicelo | Outdoor High Brightn |
| Isigqibo | 1920×720 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 1500:1 |
| Imibala | 16.7M |
| Isibane ngasemva | 4 |
| Ujongano | LVDS |
| umenzi | HannStar |
| ubungakanani besikrini | 10.3 inch |
| inombolo pixel | 1920(RGB)×720 200PPI |
| indawo esebenzayo(mm) | 243.648 × 91.368 (H×V) |
| indawo ye-bezel(mm) | 246.7 × 94.4 (H×V) |
| ukukhanya | 1000 cd/m² (Typ.) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| umbono omhle kwi | Symmetry |
| ubunzulu bombala | 16.7M 70% NTSC |
| ubunzima | TBD |
| izinga lokuhlaziya | 60Hz |
| uhlobo lomqondiso | LVDS (2 ch, 8-bit) , 60 pins FPC |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -40 ~ 95 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| igama lemodeli | HSD103JPW2-H10 |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| ilungiselelo | RGB Vertical Stripe |
| Ulwandlalo(mm) | 258.8 × 110 × 17 (H×V×D) |
| unyango | Antiglare, Hard coating (3H) |
| umlinganiselo wokuchasana | 1500 : 1 (Typ.) (TM) |
| impendulo | 30 (Max.)(Tr+Td) ms |
| imo yomsebenzi | IPS Pro, Normally Black, Transmissive |
| isibane esingasemva | 4 strings WLED , 20K hours , No Driver |
| esetyenziselwa | Outdoor High Brightness Automotive Display |
| isikrini esibanjwayo | Without |
