| Inombolo yendawo | HSD101JFW1-C11 |
| Uphawu | HannStar |
| Ubungakanani | 10.1 |
| Isicelo | Automotive Display |
| Isigqibo | 1024×600 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 16.2M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | HannStar |
| imodeli | HSD101JFW1-C11 |
| ubungakanani bediagonal | 10.1 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 222.72(H)×125.28(V) mm |
| ulwandlalo mfiliba. | 235(H)×143(V) ×6.3(D) mm |
| indawo ye-bezel | 226(H)×128.5(V) mm |
| unyango | Hard coating (3H) |
| ukukhanya | 500 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 800:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 25 (Typ.)(Tr+Td) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| indlela yokusebenza | IPS Pro, Normally Black, Transflective |
| umbala inkxaso | 16.2M 45% NTSC |
| umthombo wokukhanya | WLED [6S7P] , 20K hours , W/O Driver |
| ubunzima | 265/275g (Typ./Max.) |
| yenzelwe | Automotive Display |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | LVDS (1 ch, 8-bit) , 60 pins FPC |
| ukunikezwa Amandla | 3.3/12.5/20/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| okusingqongileyo | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
