Inombolo yendawo | G150XTN03.8 |
Uphawu | AUO |
Ubungakanani | 15.0 |
Isicelo | Industrial |
Isigqibo | 1024×768 |
Ukuqamba | LCM , a-Si TFT-LCD |
Ukuqaqamba | |
CR | 800:1 |
Imibala | 262K/16.2M |
Isibane ngasemva | WLED |
Ujongano | eDP |
umenzi | AUO |
ubungakanani besikrini | 15.0 inch |
inombolo pixel | 1024(RGB)×768 (XGA) 85PPI |
indawo esebenzayo(mm) | 304.128 × 228.096 (H×V) |
indawo ye-bezel(mm) | 312.55 × 236.25 (H×V) |
ukukhanya | 400 cd/m² (Typ.) |
i-engile yokujonga | 80/80/70/80 (Typ.)(CR≥10) |
umbono omhle kwi | - |
ubunzulu bombala | 262K/16.2M 60% NTSC |
ubunzima | 720g (Max.) |
izinga lokuhlaziya | 60Hz |
uhlobo lomqondiso | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
unikezelo lombane | 3.3V (Typ.) |
max. amanqaku | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
igama lemodeli | G150XTN03.8 |
uhlobo lwesikrini | LCM , a-Si TFT-LCD |
ilungiselelo | RGB Vertical Stripe |
Ulwandlalo(mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
unyango | Antiglare, Hard coating (3H) |
umlinganiselo wokuchasana | 800 : 1 (Typ.) (TM) |
impendulo | 5.7/3.2 (Typ.)(Tr/Td) ms |
imo yomsebenzi | TN, Normally White, Transmissive |
isibane esingasemva | WLED , 50K hours , With LED Driver |
esetyenziselwa | Industrial |
isikrini esibanjwayo | Without |
