| Inombolo yendawo | G070VAN01.0 |
| Uphawu | AUO |
| Ubungakanani | 7.0 |
| Isicelo | Industrial |
| Isigqibo | 800×480 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 1300:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | AUO |
| imodeli | G070VAN01.0 |
| ubungakanani bediagonal | 7.0 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 800×480(RGB) [WVGA] 133PPI |
| uqwalaselo | RGB Horizontal Stripe |
| indawo esebenzayo | 152.4(H)×91.44(V) mm |
| ulwandlalo mfiliba. | 166.6(H)×107(V) ×10(D) mm |
| indawo ye-bezel | 154.2(H)×93.24(V) mm |
| unyango | Antiglare |
| ukukhanya | 480 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1300:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 11/19 (Max.)(Tr/Td) |
| i-engile yokujonga | 89/89/89/89 (Typ.)(CR≥10) |
| indlela yokusebenza | AHVA, Normally Black, Transmissive |
| umbala inkxaso | 262K/16.7M 70% NTSC |
| umthombo wokukhanya | WLED [7S2P] , 50K hours , W/O Driver |
| ubunzima | 175±10%g |
| yenzelwe | Industrial |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
