| Inombolo yendawo | EV101WUM-N20 |
| Uphawu | BOE |
| Ubungakanani | 10.1 |
| Isicelo | Medical Imaging |
| Isigqibo | 1920×1200 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 900:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | BOE |
| imodeli | EV101WUM-N20 |
| ubungakanani bediagonal | 10.1 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 1920(RGB)×1200 [WUXGA] 224PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 216.806(H)×135.504(V) mm |
| ulwandlalo mfiliba. | 229.45(H)×149.22(V) mm |
| ukukhanya | 600 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 900:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 30 (Typ.)(Tr+Td) |
| i-engile yokujonga | 80/80/80/80 (Typ.)(CR≥10) |
| indlela yokusebenza | ADS, Normally Black, Transmissive |
| umbala inkxaso | 16.7M 72% NTSC |
| umthombo wokukhanya | WLED , W/O Driver |
| ubunzima | - |
| yenzelwe | Medical Imaging |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | LVDS (1 ch, 8-bit) , 45 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -25 ~ 80 °C |
