| Inombolo yendawo | EMA-101402-01 |
| Uphawu | eMagin |
| Ubungakanani | 0.77 |
| Isicelo | HMD VR AR |
| Isigqibo | 1280×1024 |
| Ukuqamba | OLED, Si-OLED |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | Grayscale(G) |
| Isibane ngasemva | self |
| Ujongano | Parallel |
| umenzi | eMagin |
| igama lemodeli | EMA-101402-01 |
| ubungakanani besikrini | 0.77 inch |
| uhlobo lwesikrini | OLED, Si-OLED |
| inombolo pixel | 1280(LCR)×1024 (SXGA) 2116PPI |
| ilungiselelo | LCR Vertical Stripe |
| indawo esebenzayo(mm) | 15.36 × 12.29 (H×V) |
| Ulwandlalo(mm) | 22.9 × 16.4 (H×V×D) |
| ukukhanya | 5000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1000 : 1 (Min.) (TM) |
| i-engile yokujonga | - |
| impendulo | - |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | - |
| ubunzulu bombala | Grayscale(G) |
| isibane esingasemva | self |
| ubunzima | 2.50g (Typ.) |
| esetyenziselwa | HMD VR AR |
| izinga lokuhlaziya | 85Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | Parallel RGB , Connector 50 pins |
| unikezelo lombane | 2.5/5/-1.4/-2.0V (Typ.)(VDD/VAN/VCOM/VPG) |
| max. amanqaku | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
