| Inombolo yendawo | CLAA080WK02 XN |
| Uphawu | CPT |
| Ubungakanani | 8.0 |
| Isicelo | Automotive Display |
| Isigqibo | 1280×720 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 900:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | CPT |
| imodeli | CLAA080WK02 XN |
| ubungakanani bediagonal | 8.0 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 1280(RGB)×720 [WXGA] 183PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 177.024(H)×99.576(V) mm |
| ulwandlalo mfiliba. | 186.5(H)×117.22(V) ×13.1(D) mm |
| indawo ye-bezel | 179.03(H)×101.58(V) mm |
| unyango | Antiglare (Haze 25%) |
| ukukhanya | 600 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 900:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 25 (Typ.)(Tr+Td) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| indlela yokusebenza | HFFS, Normally Black, Transmissive |
| umbala inkxaso | 262K/16.7M 70% NTSC |
| umthombo wokukhanya | WLED [5S4P] , 30K hours , W/O Driver |
| ubunzima | TBD |
| yenzelwe | Automotive Display |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| ukunikezwa Amandla | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| okusingqongileyo | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA080XA01BW | CPT | 8.0 | 1024×768 |
