| Inombolo yendawo | CLAA070LQ02 XN |
| Uphawu | CPT |
| Ubungakanani | 7.0 |
| Isicelo | Automotive Display |
| Isigqibo | 800×480 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 900:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | 7S2P |
| Ujongano | LVDS |
| umenzi | CPT |
| igama lemodeli | CLAA070LQ02 XN |
| ubungakanani besikrini | 7.0 inch |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 800(RGB)×480 (WVGA) 133PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 152.4 × 91.44 (H×V) |
| Ulwandlalo(mm) | 165 × 104 × 7.3 (H×V×D) |
| indawo ye-bezel(mm) | 154.4 × 93.44 (H×V) |
| unyango | Antiglare (Haze 25%) |
| ukukhanya | 760 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 900 : 1 (Typ.) (TM) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| impendulo | 25 (Typ.)(Tr+Tf) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | HFFS, Normally Black, Transmissive |
| ubunzulu bombala | 262K/16.7M 70% NTSC |
| isibane esingasemva | 7S2P WLED , 30K hours , No Driver |
| ubunzima | 175g (Typ.) |
| esetyenziselwa | Automotive Display |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (1 ch, 6/8-bit) , FPC 60 pins |
| unikezelo lombane | 3.3/13.0/20.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. amanqaku | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA070LC0FCT | CPT | 7.0 | 800×480 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| CLAA070LJ01CW | CPT | 7.0 | 800×480 |
| CLAA070NC0DCT | CPT | 7.0 | 1024×600 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| CLAA070WA01 | CPT | 7.0 | 480×234 |
| CLAA070WP03 | CPT | 7.0 | 800×1280 |
| CLAA070WP06G XG | CPT | 7.0 | 800×1280 |
