| Inombolo yendawo | C084XAN01.0 |
| Uphawu | AUO |
| Ubungakanani | 8.4 |
| Isicelo | Automotive Display |
| Isigqibo | 1024×768 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| umenzi | AUO |
| ubungakanani besikrini | 8.4 inch |
| inombolo pixel | 1024(RGB)×768 (XGA) 152PPI |
| indawo esebenzayo(mm) | 170.496 × 127.872 (H×V) |
| ukukhanya | - |
| i-engile yokujonga | - |
| umbono omhle kwi | Symmetry |
| ubunzulu bombala | 16.7M |
| ubunzima | - |
| izinga lokuhlaziya | 60Hz |
| uhlobo lomqondiso | LVDS (1 ch, 8-bit) , 40 pins Connector |
| max. amanqaku | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
| igama lemodeli | C084XAN01.0 |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| ilungiselelo | RGB Vertical Stripe |
| Ulwandlalo(mm) | - |
| umlinganiselo wokuchasana | 800 : 1 (Typ.) (TM) |
| impendulo | 30 (Max.)(Tr+Td) ms |
| imo yomsebenzi | AHVA, Normally Black, Transmissive |
| isibane esingasemva | WLED |
| esetyenziselwa | Automotive Display |
| isikrini esibanjwayo | Without |
