| Inombolo yendawo | B156XTT01.2 |
| Uphawu | AUO |
| Ubungakanani | 15.6 |
| Isicelo | Laptop |
| Isigqibo | 1366×768 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 262K |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| umenzi | AUO |
| ubungakanani besikrini | 15.6 inch |
| inombolo pixel | 1366(RGB)×768 (WXGA) 100PPI |
| indawo esebenzayo(mm) | 344.232 × 193.536 (H×V) |
| indawo ye-bezel(mm) | - |
| ukukhanya | 200 cd/m² (Typ.) |
| i-engile yokujonga | 45/45/15/35 (Typ.)(CR≥10) |
| umbono omhle kwi | 6 o'clock |
| ubunzulu bombala | 262K 45% NTSC |
| imilo yolwandlalo | Slim (PCBA Flat, T≤3.2mm) |
| izinga lokuhlaziya | 60Hz |
| uhlobo lomqondiso | LVDS (1 ch, 6-bit) , 40 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| igama lemodeli | B156XTT01.2 (AUO12EC) |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| ilungiselelo | RGB Vertical Stripe |
| Ulwandlalo(mm) | 364.9 × 224.56 × 5.2 (H×V×D) |
| unyango | Glare (Haze 0%), Hard coating (7H) |
| umlinganiselo wokuchasana | 500 : 1 (Typ.) (TM) |
| impendulo | 8 (Typ.)(G to G) ms |
| imo yomsebenzi | TN, Normally White, Transmissive |
| isibane esingasemva | WLED , 15K hours , With LED Driver |
| esetyenziselwa | Laptop |
| isikrini esibanjwayo | PCAP, Optical Bonding |
