Inombolo yendawo | B141EW04 V7 |
Uphawu | AUO |
Ubungakanani | 14.1 |
Isicelo | NBPC |
Isigqibo | 1280×800 |
Ukuqamba | LCM |
Ukuqaqamba | 200 |
CR | 400:1 |
Imibala | 262K |
Isibane ngasemva | CCFL |
Ujongano | LVDS |
uphawu lwephaneli | AUO |
imodeli yephaneli | B141EW04 V7 |
uhlobo lwephaneli | a-Si TFT-LCD , LCM |
ubungakanani bephaneli | 14.1 inch |
isisombululo | 1280(RGB)×800 , WXGA |
imowudi yokubonisa | TN, Normally White, Transmissive |
indawo esebenzayo | 303.36×189.6 mm |
ulwandlalo | 319.5×205.5×5.5 mm |
isitayile semilo | Wedge (PCBA Bent, Depth ≥5.2mm) |
umphezulu | Antiglare, Hard coating (3H), Antireflection |
ukuqaqamba | 200 cd/m² (Typ.) |
umlinganiselo wokuchasana | 400:1 (Typ.) |
bonisa imibala | 262K (6-bit), CIE193145% |
ixesha lokuphendula | 5/11 (Typ.)(Tr/Td) |
i-engile yokujonga | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
rhoqo | 60Hz |
uhlobo lwesibane | 1 pcsCCFLWithout Driver |
ujongano lomqondiso | LVDS (1 ch, 6-bit), 30 pins |
igalelo lombane | 3.3V (Typ.) |
isicelo | NBPC |
B141EW02 V3 | AUO | 14.1 | 1280×800 |
B141EW03 V3 | AUO | 14.1 | 1280×800 |
B141EW04 V0 | AUO | 14.1 | 1280×800 |
B141EW04 V4 | AUO | 14.1 | 1280×800 |
B141EW04 V5 | AUO | 14.1 | 1280×800 |
B141EW04 V6 | AUO | 14.1 | 1280×800 |
B141EW04 V7 | AUO | 14.1 | 1280×800 |
B141EW05 V0 | AUO | 14.1 | 1280×800 |
B141EW05 V2 | AUO | 14.1 | 1280×800 |
B141EW05 V4 | AUO | 14.1 | 1280×800 |
B141XG03 V2 | AUO | 14.1 | 1024×768 |
LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
LP133WX2-TLD1 | LG Display | 13.3 | 1280×800 |
LP140WD1-TLA1 | LG Display | 14.0 | 1600×900 |
LP141WX1-TL02 | LG Display | 14.1 | 1280×800 |
LP171WP4-TLR1 | LG Display | 17.1 | 1440×900 |
LQ154M1LW2A | SHARP | 15.4 | 1920×1200 |
LTD121KX5V | TOSHIBA | 12.1 | 1280×800 |
LTN160AT04-N01 | Samsung | 16.0 | 1366×768 |
N101BGE-L31 | Innolux | 10.1 | 1366×768 |
