AUO B140RW02 V1 idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


B140RW02 V1

B140RW02 V1
B140RW02 V1
B140RW02 V1
B140RW02 V1 thumb B140RW02 V1 thumb B140RW02 V1 thumb
Uphawu
AUO
Ubungakanani
14.0
Isicelo
NBPC
Isigqibo
1600×900
Ukuqamba
LCM
Ukuqaqamba
250
CR
400:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
20
Iinkcukacha

Inombolo yendawo B140RW02 V1
UphawuAUO
Ubungakanani14.0
IsiceloNBPC
Isigqibo1600×900
UkuqambaLCM
Ukuqaqamba250
CR400:1
Imibala262K
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliAUO
imodeli yephaneliB140RW02 V1
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli14.0 inch
isisombululo1600(RGB)×900 , HD+
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo309.6×174.15 mm
ulwandlalo320.4×205.1×3.6 mm
isitayile semiloFlat (PCBA Flat, Depth 3.4~4.0mm)
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba250 cd/m² (Typ.)
umlinganiselo wokuchasana400:1 (Typ.)
bonisa imibala262K (6-bit), CIE193145%
ixesha lokuphendula8 (Typ.)(Tr+Td)
i-engile yokujonga45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoLVDS (2 ch, 6-bit), 40 pins
igalelo lombane3.3V (Typ.)
isiceloNBPC
Umzekelo woSapho
B140RTN01.0 AUO 14.0 1600×900
B140RTN02.1 AUO 14.0 1600×900
B140RTN02.3 AUO 14.0 1600×900
B140RTN03.0 AUO 14.0 1600×900
B140RW01 V0 AUO 14.0 1600×900
B140RW01 V2 AUO 14.0 1600×900
B140RW02 V0 AUO 14.0 1600×900
B140RW02 V1 AUO 14.0 1600×900
B140RW02 V2 AUO 14.0 1600×900
B140RW03 V1 AUO 14.0 1600×900
