| Inombolo yendawo | B116XTN02.5 |
| Uphawu | AUO |
| Ubungakanani | 11.6 |
| Isicelo | Laptop Netbook PC |
| Isigqibo | 1366×768 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 400:1 |
| Imibala | 262K |
| Isibane ngasemva | WLED |
| Ujongano | eDP |
| umenzi | AUO |
| ubungakanani besikrini | 11.6 inch |
| inombolo pixel | 1366(RGB)×768 (WXGA) 135PPI |
| indawo esebenzayo(mm) | 256.125 × 144 (H×V) |
| indawo ye-bezel(mm) | - |
| ukukhanya | 250 cd/m² (Typ.) |
| i-engile yokujonga | 45/45/15/35 (Typ.)(CR≥10) |
| umbono omhle kwi | 6 o'clock |
| ubunzulu bombala | 262K 45% NTSC |
| imilo yolwandlalo | Slim (PCBA Flat, T≤3.2mm) |
| izinga lokuhlaziya | 60Hz |
| uhlobo lomqondiso | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| igama lemodeli | B116XTN02.5 (AUO255C) |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| ilungiselelo | RGB Vertical Stripe |
| Ulwandlalo(mm) | 278 × 168 × 3 (H×V×D) |
| unyango | Antiglare |
| umlinganiselo wokuchasana | 400 : 1 (Typ.) (TM) |
| impendulo | 8 (Typ.)(Tr+Td) ms |
| imo yomsebenzi | TN, Normally White, Transmissive |
| isibane esingasemva | WLED , 15K hours , With LED Driver |
| esetyenziselwa | Laptop Netbook PC |
| isikrini esibanjwayo | Without |
| B116XTK01.1 | AUO | 11.6 | 1366×768 |
| B116XTN01.0 HW5A | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| B116XW01 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V1 | AUO | 11.6 | 1366×768 |
| B116XW03 V0 | AUO | 11.6 | 1366×768 |
| B116XW03 V1 | AUO | 11.6 | 1366×768 |
| B116XW05 V001 | AUO | 11.6 | 1366×768 |
| B116XW05 V004 | AUO | 11.6 | 1366×768 |
