AUO B116XTN02.3 HW4A idatadata, iinkcukacha, izitokhwe, usetyenziso www.looklcd-xh.com
LookLCD LookLCD


B116XTN02.3 HW4A

B116XTN02.3 HW4A
B116XTN02.3 HW4A
B116XTN02.3 HW4A thumb B116XTN02.3 HW4A thumb
Uphawu
AUO
Ubungakanani
11.6
Isicelo
NOPC
Isigqibo
1366×768
Ukuqamba
LCM
Ukuqaqamba
220
CR
400:1
Imibala
262K
Isibane ngasemva
WLED
Ujongano
eDP
In Stock
2000
Iinkcukacha

Inombolo yendawo B116XTN02.3 HW4A
UphawuAUO
Ubungakanani11.6
IsiceloNOPC
Isigqibo1366×768
UkuqambaLCM
Ukuqaqamba220
CR400:1
Imibala262K
Isibane ngasemvaWLED
UjonganoeDP
uphawu lwephaneliAUO
imodeli yephaneliB116XTN02.3 HW4A
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli11.6 inch
isisombululo1366(RGB)×768 , WXGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo256.125×144 mm
ulwandlalo278×168×3 mm
isitayile semiloSlim (PCBA Flat, Depth ≤3.2mm)
umphezuluAntiglare, Hard coating (3H)
ukuqaqamba220 cd/m² (Typ.)
umlinganiselo wokuchasana400:1 (Typ.)
bonisa imibala262K (6-bit), CIE193145%
ixesha lokuphendula8 (Typ.)(Tr+Td)
i-engile yokujonga45/45/15/35 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibaneWLEDEmbedded (LED Driver)
ujongano lomqondisoeDP (1 Lane), 30 pins
igalelo lombane3.3V (Typ.)
isiceloNOPC
