| Inombolo yendawo | AV080WSM-NW2 |
| Uphawu | BOE |
| Ubungakanani | 8.0 |
| Isicelo | Automotive Display |
| Isigqibo | 1024×600 |
| Ukuqamba | LCM, a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | 3S10P |
| Ujongano | LVDS |
| umenzi | BOE |
| igama lemodeli | AV080WSM-NW2 |
| ubungakanani besikrini | 8.0 inch |
| uhlobo lwesikrini | LCM, a-Si TFT-LCD |
| inombolo pixel | 1024(RGB)×600 (WSVGA) 148PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 176.64 × 99.36 (H×V) |
| Ulwandlalo(mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| indawo ye-bezel(mm) | 180.1 × 103.4 (H×V) |
| unyango | - |
| ukukhanya | 600 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 800 : 1 (Typ.) (TM) |
| i-engile yokujonga | 80/80/80/80 (Typ.)(CR≥10) |
| impendulo | 25 (Typ.)(Tr+Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | ADS, Normally Black, Transmissive |
| ubunzulu bombala | 262K/16.7M 50% NTSC |
| isibane esingasemva | 3S10P WLED , 30K hours , No Driver |
| ubunzima | 176/180g (Typ./Max.) |
| esetyenziselwa | Automotive Display |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| unikezelo lombane | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| AV080WSM-NW3 | BOE | 8.0 | 1024×600 |
| B080EAN02.0 | AUO | 8.0 | 800×1280 |
| EJ080NA-05B | Innolux | 8.0 | 800×600 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| LQ080Y5DR01 | SHARP | 8.0 | 800×480 |
| LQ080Y5DZ03 | SHARP | 8.0 | 800×480 |
| LTA080B441A | TOSHIBA | 8.0 | 480×234 |
| PD080SL3 | E Ink | 8.0 | 800×600 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
