AT101WSM-NW0-3800(3900)

AT101WSM-NW0-3800(3900)
AT101WSM-NW0-3800(3900)
AT101WSM-NW0-3800(3900) thumb AT101WSM-NW0-3800(3900) thumb
Uphawu
BOE
Ubungakanani
10.1
Isicelo
CNS
Isigqibo
1024×600
Ukuqamba
LCM
Ukuqaqamba
500
CR
600:1
Imibala
262K/16.7M
Isibane ngasemva
WLED
Ujongano
LVDS
In Stock
1338
Iinkcukacha

Inombolo yendawo AT101WSM-NW0-3800(3900)
UphawuBOE
Ubungakanani10.1
IsiceloCNS
Isigqibo1024×600
UkuqambaLCM
Ukuqaqamba500
CR600:1
Imibala262K/16.7M
Isibane ngasemvaWLED
UjonganoLVDS
uphawu lwephaneliBOE
imodeli yephaneliAT101WSM-NW0-3800(3900)
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli10.1 inch
isisombululo1024(RGB)×600 , WSVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo222.72×125.28 mm
ulwandlalo235×143×4.8 mm
umphezuluAntiglare (Haze 25%)
ukuqaqamba500 cd/m² (Typ.)
umlinganiselo wokuchasana600:1 (Typ.)
bonisa imibala262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150%
ixesha lokuphendula25 (Typ.)(Tr+Tf)
i-engile yokujonga80/80/60/70 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane3S7PWLEDWithout Driver
ujongano lomqondisoLVDS (1 ch, 6/8-bit), 60 pins
igalelo lombane3.3/9.6V (Typ.)(VDD/AVDD)
isiceloCNS
