| Inombolo yendawo | AM480272H3TMQW-TW1H |
| Uphawu | AMPIRE |
| Ubungakanani | 4.3 |
| Isicelo | Industrial |
| Isigqibo | 480×272 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 250:1 |
| Imibala | 65K/262K |
| Isibane ngasemva | WLED |
| Ujongano | 8/9/16/18-bit |
| uphawu | AMPIRE |
| imodeli | AM480272H3TMQW-TW1H |
| ubungakanani bediagonal | 4.3 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 480(RGB)×272 [WQVGA] 128PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 95.04(H)×53.856(V) mm |
| ulwandlalo mfiliba. | 105.5(H)×67.2(V) ×7.91(D) mm |
| ukukhanya | 400 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 250:1 (Typ.) (TM) |
| Jonga indlela | 6 o'clock |
| ixesha lokuphendula | 15/35 (Typ.)(Tr/Td) |
| i-engile yokujonga | 70/70/35/55 (Typ.)(CR≥10) |
| indlela yokusebenza | TN, Normally White, Transmissive |
| umbala inkxaso | 65K/262K 52% NTSC |
| umthombo wokukhanya | WLED [7S1P] , 15K hours , W/O Driver |
| ubunzima | TBD |
| yenzelwe | Industrial |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | 4-wire Resistive Touch |
| uhlobo lojongano | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
