| Inombolo yendawo | AM-800600M3TNQW-02H |
| Uphawu | AMPIRE |
| Ubungakanani | 8.4 |
| Isicelo | Industrial |
| Isigqibo | 800×600 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 600:1 |
| Imibala | 262K |
| Isibane ngasemva | 12S4P |
| Ujongano | LVDS |
| umenzi | AMPIRE |
| igama lemodeli | AM-800600M3TNQW-02H |
| ubungakanani besikrini | 8.4 inch |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| inombolo pixel | 800(RGB)×600 (SVGA) 119PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 170.4 × 127.8 (H×V) |
| Ulwandlalo(mm) | 203 × 145.5 × 10.4 (H×V×D) |
| indawo ye-bezel(mm) | 174.15 × 131.2 (H×V) |
| unyango | - |
| ukukhanya | 350 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 600 : 1 (Typ.) (TM) |
| i-engile yokujonga | 75/75/60/70 (Typ.)(CR≥10) |
| impendulo | 8 (Typ.)(Tr+Td) ms |
| umbono omhle kwi | - |
| imo yomsebenzi | TN, Normally White, Transmissive |
| ubunzulu bombala | 262K 70% NTSC |
| isibane esingasemva | 12S4P WLED , 50K hours , With LED Driver |
| ubunzima | 280g |
| esetyenziselwa | Industrial |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (1 ch, 6-bit) , 20 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
