| Inombolo yendawo | AM-800480R2TMQW-U0H |
| Uphawu | AMPIRE |
| Ubungakanani | 7.0 |
| Isicelo | Industrial |
| Isigqibo | 800×480 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 250:1 |
| Imibala | 65K |
| Isibane ngasemva | WLED |
| Ujongano | UART |
| umenzi | AMPIRE |
| igama lemodeli | AM-800480R2TMQW-U0H |
| ubungakanani besikrini | 7.0 inch |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| inombolo pixel | 800(RGB)×480 (WVGA) 133PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 152.4 × 91.44 (H×V) |
| Ulwandlalo(mm) | 178.5 × 110 × 20.4 (H×V×D) |
| indawo ye-bezel(mm) | 155.3 × 94.3 (H×V) |
| unyango | - |
| ukukhanya | 400 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 250 : 1 (Typ.) (TM) |
| i-engile yokujonga | 70/70/60/60 (Typ.)(CR≥10) |
| impendulo | 50 (Typ.)(Tr+Td) ms |
| umbono omhle kwi | - |
| imo yomsebenzi | TN, Normally White, Transmissive |
| ubunzulu bombala | 65K 48% NTSC |
| isibane esingasemva | WLED , With LED Driver |
| ubunzima | - |
| esetyenziselwa | Industrial |
| izinga lokuhlaziya | - |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | UART , 8 pins Connector |
| unikezelo lombane | 4.6/26.0V (Min./Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
