| Inombolo yendawo | AM-800480LTMQW-WAH |
| Uphawu | AMPIRE |
| Ubungakanani | 5.0 |
| Isicelo | Industrial |
| Isigqibo | 800×480 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 262K |
| Isibane ngasemva | WLED |
| Ujongano | CPU |
| uphawu | AMPIRE |
| imodeli | AM-800480LTMQW-WAH |
| ubungakanani bediagonal | 5.0 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 800(RGB)×480 [WVGA] 188PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 108(H)×64.8(V) mm |
| ulwandlalo mfiliba. | 118.5(H)×77.1(V) ×6.37(D) mm |
| indawo ye-bezel | 110.6(H)×67.4(V) mm |
| unyango | - |
| ukukhanya | 470 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 500:1 (Typ.) (TM) |
| Jonga indlela | - |
| ixesha lokuphendula | 15/35 (Typ.)(Tr/Td) |
| i-engile yokujonga | 70/70/70/50 (Typ.)(CR≥10) |
| indlela yokusebenza | TN, Normally White, Transmissive |
| umbala inkxaso | 262K 52% NTSC |
| umthombo wokukhanya | WLED [3S6P] , With LED Driver |
| ubunzima | TBD |
| yenzelwe | Industrial |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | CPU , 40 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
