| Inombolo yendawo | AM-800480AZTMQW-05H |
| Uphawu | AMPIRE |
| Ubungakanani | 5.0 |
| Isicelo | Industrial |
| Isigqibo | 800×480 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 600:1 |
| Imibala | 262K |
| Isibane ngasemva | WLED |
| Ujongano | |
| uphawu | AMPIRE |
| imodeli | AM-800480AZTMQW-05H |
| ubungakanani bediagonal | 5.0 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 800(RGB)×480 [WVGA] 188PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 108(H)×64.8(V) mm |
| ulwandlalo mfiliba. | 118.5(H)×77.1(V) ×7.41(D) mm |
| indawo ye-bezel | 110.6(H)×67.4(V) mm |
| unyango | - |
| ukukhanya | 500 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 600:1 (Typ.) (TM) |
| Jonga indlela | - |
| ixesha lokuphendula | 2/6 (Typ.)(Tr/Td) |
| i-engile yokujonga | 75/75/70/60 (Typ.)(CR≥10) |
| indlela yokusebenza | TN, Normally White, Transmissive |
| umbala inkxaso | 262K 47% NTSC |
| umthombo wokukhanya | WLED [3S7P] , 30K hours , With LED Driver |
| ubunzima | - |
| yenzelwe | Industrial |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
