| Inombolo yendawo | AM-1024768V1TZQW-A0H |
| Uphawu | AMPIRE |
| Ubungakanani | 8.4 |
| Isicelo | Industrial |
| Isigqibo | 1024×768 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 1000:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | AMPIRE |
| imodeli | AM-1024768V1TZQW-A0H |
| ubungakanani bediagonal | 8.4 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 1024(RGB)×768 [XGA] 152PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 170.8(H)×128.1(V) mm |
| ulwandlalo mfiliba. | 203(H)×145.5(V) ×8(D) mm |
| indawo ye-bezel | 174.15(H)×131.2(V) mm |
| unyango | - |
| ukukhanya | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 1000:1 (Typ.) (TM) |
| Jonga indlela | Symmetry |
| ixesha lokuphendula | 30 (Typ.)(Tr+Td) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| indlela yokusebenza | IPS, Normally Black, Transmissive |
| umbala inkxaso | 16.7M |
| umthombo wokukhanya | WLED [6S6P] , 50K hours , With LED Driver |
| ubunzima | - |
| yenzelwe | Industrial |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | Without |
| uhlobo lojongano | LVDS (1 ch, 8-bit) , 20 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AM-1024768M2TMQW-T00H | AMPIRE | 9.7 | 1024×768 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| AM-1024768RTNQW-00H | AMPIRE | 12.0 | 1024×768 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL8060BC21-02 | NLT | 8.4 | 800×600 |
| NL8060BC21-11 | NLT | 8.4 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
