| Inombolo yendawo | AM-1024600L2HMQW-T01H |
| Uphawu | AMPIRE |
| Ubungakanani | 10.1 |
| Isicelo | Industrial |
| Isigqibo | 1024×600 |
| Ukuqamba | a-Si TFT-LCD, LCM |
| Ukuqaqamba | |
| CR | 500:1 |
| Imibala | 262K |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| uphawu | AMPIRE |
| imodeli | AM-1024600L2HMQW-T01H |
| ubungakanani bediagonal | 10.1 inch |
| uhlobo | a-Si TFT-LCD, LCM |
| ifomathi ye-pixel | 1024(RGB)×600 [WSVGA] 117PPI |
| uqwalaselo | RGB Vertical Stripe |
| indawo esebenzayo | 222.72(H)×125.28(V) mm |
| ulwandlalo mfiliba. | 235(H)×145.8(V) ×9.8(D) mm |
| indawo ye-bezel | 225.92(H)×128.48(V) mm |
| unyango | - |
| ukukhanya | 800 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 500:1 (Typ.) (TM) |
| Jonga indlela | - |
| ixesha lokuphendula | 4/12 (Typ.)(Tr/Td) |
| i-engile yokujonga | 70/70/70/50 (Typ.)(CR≥10) |
| indlela yokusebenza | TN, Normally White, Transmissive |
| umbala inkxaso | 262K 47% NTSC |
| umthombo wokukhanya | WLED [6S6P] , 50K hours , With LED Driver |
| ubunzima | TBD |
| yenzelwe | Industrial |
| umgangatho wefreyimu | 60Hz |
| indawo yokuthintela | 4-wire Resistive Touch |
| uhlobo lojongano | LVDS (1 ch, 6-bit) , 30 pins Connector |
| ukunikezwa Amandla | 3.3V (Typ.) |
| okusingqongileyo | Operating Temperature: -5 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
