| Inombolo yendawo | AM-1024600K7TMQW-T53H |
| Uphawu | AMPIRE |
| Ubungakanani | 7.0 |
| Isicelo | Industrial |
| Isigqibo | 1024×600 |
| Ukuqamba | a-Si TFT-LCD , LCM |
| Ukuqaqamba | |
| CR | 700:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | 5S3P |
| Ujongano | LVDS |
| uphawu lwephaneli | AMPIRE |
| ubungakanani bephaneli | 7.0" |
| isisombululo | 1024(RGB)×600, WSVGA, 169PPI |
| indawo yokubonisa | 153.6(W)×90(H) mm |
| ubungakanani bamagqabantshintshi | 165.5(W)×104.44(H) ×11.93(D) mm |
| ukuqaqamba | 425 cd/m² (Typ.) |
| i-engile yokujonga | 75/75/70/75 (Typ.)(CR≥10) |
| eyona mbono kwi | 6 o'clock |
| bonisa imibala | 262K/16.7M |
| rhoqo | 60Hz |
| Ubunzima bephaneli | TBD |
| ujongano lomqondiso | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| igalelo lombane | 3.3V (Typ.) |
| okusingqongileyo | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| imodeli yephaneli | AM-1024600K7TMQW-T53H |
| uhlobo lwephaneli | a-Si TFT-LCD , LCM |
| ifomathi ye-pixel | RGB Vertical Stripe |
| ukuvulwa kwe-bezel | - |
| umphezulu | - |
| umlinganiselo wokuchasana | 700:1 (Typ.) (TM) |
| imowudi yokubonisa | TN, Normally White, Transmissive |
| ixesha lokuphendula | 20/20 (Typ.)(Tr/Td) |
| uhlobo lwesibane | 5S3P WLED , 50K hours , With LED Driver |
| isikrini esibanjwayo | PCAP |
| isicelo | Industrial |
