| Inombolo yendawo | AM-1024600K5TMQW-04H |
| Uphawu | AMPIRE |
| Ubungakanani | 7.0 |
| Isicelo | Industrial Outdoor H |
| Isigqibo | 1024×600 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 700:1 |
| Imibala | 262K/16.7M |
| Isibane ngasemva | 8S3P |
| Ujongano | LVDS |
| umenzi | AMPIRE |
| ubungakanani besikrini | 7.0 inch |
| inombolo pixel | 1024(RGB)×600 (WSVGA) 169PPI |
| indawo esebenzayo(mm) | 153.6 × 90 (H×V) |
| indawo ye-bezel(mm) | 156.2 × 92.6 (H×V) |
| ukukhanya | 1000 cd/m² (Typ.) |
| i-engile yokujonga | 75/75/70/75 (Typ.)(CR≥10) |
| umbono omhle kwi | - |
| ubunzulu bombala | 262K/16.7M |
| ubunzima | TBD |
| izinga lokuhlaziya | 60Hz |
| uhlobo lomqondiso | LVDS (1 ch, 6/8-bit) , 40 pins FPC |
| unikezelo lombane | 3.3/11/16/-6.8V (Typ.)(VCC/AVDD/VGH/VGL) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| igama lemodeli | AM-1024600K5TMQW-04H |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| ilungiselelo | RGB Vertical Stripe |
| Ulwandlalo(mm) | 165.5 × 104.44 × 5.3 (H×V×D) |
| unyango | Glare (Haze 0%), Hard coating |
| umlinganiselo wokuchasana | 700 : 1 (Typ.) (TM) |
| impendulo | 20/20 (Typ.)(Tr/Td) ms |
| imo yomsebenzi | TN, Normally White, Transmissive |
| isibane esingasemva | 8S3P WLED , 50K hours , No Driver |
| esetyenziselwa | Industrial Outdoor High Brightness |
| isikrini esibanjwayo | Without |
