| Inombolo yendawo | AM-1024600DTZQW-A6H |
| Uphawu | AMPIRE |
| Ubungakanani | 7.0 |
| Isicelo | Industrial Outdoor H |
| Isigqibo | 1024×600 |
| Ukuqamba | LCM , a-Si TFT-LCD |
| Ukuqaqamba | |
| CR | 800:1 |
| Imibala | 16.7M |
| Isibane ngasemva | WLED |
| Ujongano | LVDS |
| umenzi | AMPIRE |
| igama lemodeli | AM-1024600DTZQW-A6H |
| ubungakanani besikrini | 7.0 inch |
| uhlobo lwesikrini | LCM , a-Si TFT-LCD |
| inombolo pixel | 1024(RGB)×600 (WSVGA) 170PPI |
| ilungiselelo | RGB Vertical Stripe |
| indawo esebenzayo(mm) | 154.221 × 85.92 (H×V) |
| Ulwandlalo(mm) | 164.9 × 100 (H×V×D) |
| indawo ye-bezel(mm) | 158 × 89.7 (H×V) |
| unyango | Antiglare |
| ukukhanya | 1000 cd/m² (Typ.) |
| umlinganiselo wokuchasana | 800 : 1 (Typ.) (TM) |
| i-engile yokujonga | 85/85/85/85 (Typ.)(CR≥10) |
| impendulo | 13/15 (Typ.)(Tr/Td) ms |
| umbono omhle kwi | Symmetry |
| imo yomsebenzi | IPS, Normally Black, Transmissive |
| ubunzulu bombala | 16.7M |
| isibane esingasemva | WLED , 50K hours , With LED Driver |
| ubunzima | - |
| esetyenziselwa | Industrial Outdoor High Brightness |
| izinga lokuhlaziya | 60Hz |
| isikrini esibanjwayo | Without |
| uhlobo lomqondiso | LVDS (1 ch, 8-bit) , 20 pins Connector |
| unikezelo lombane | 3.3V (Typ.) |
| max. amanqaku | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
