A070FW03 V4

A070FW03 V4
A070FW03 V4
A070FW03 V4 thumb A070FW03 V4 thumb
Uphawu
AUO
Ubungakanani
7.0
Isicelo
VDP
Isigqibo
480×234
Ukuqamba
LCM
Ukuqaqamba
400
CR
300:1
Imibala
Isibane ngasemva
CCFL
Ujongano
Analog
In Stock
104
Iinkcukacha

Inombolo yendawo A070FW03 V4
UphawuAUO
Ubungakanani7.0
IsiceloVDP
Isigqibo480×234
UkuqambaLCM
Ukuqaqamba400
CR300:1
Imibala
Isibane ngasemvaCCFL
UjonganoAnalog
uphawu lwephaneliAUO
imodeli yephaneliA070FW03 V4
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli7.0 inch
isisombululo480(RGB)×234
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo154.08×86.58 mm
ulwandlalo164.9×100 mm
umphezuluAntiglare (Haze 25%)
ukuqaqamba400 cd/m² (Typ.)
umlinganiselo wokuchasana300:1 (Typ.)
bonisa imibala
ixesha lokuphendula12/18 (Typ.)(Tr/Td)
i-engile yokujonga65/65/40/65 (Typ.)(CR≥10)(L/R/U/D)
uhlobo lwesibane1 pcsCCFLWithout Driver
ujongano lomqondisoTFT Specific Analog RGB, 26 pins
igalelo lombane5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL)
rohs:
isiceloVDP
Umzekelo woSapho
A070FW01 AUO 7.0 480×234
A070FW03 V1 AUO 7.0 480×234
A070FW03 V3 AUO 7.0 480×234
A070FW03 V4 AUO 7.0 480×234
A070FW03 V6 AUO 7.0 480×234
A070FW03 V7 AUO 7.0 480×234
A070FW03 V8 AUO 7.0 480×234
A070FW03 VB AUO 7.0 480×234
A070FW03 VD AUO 7.0 480×234
A070FW05 V1 AUO 7.0 480×234
