A030DN01 VC

A030DN01 VC
A030DN01 VC thumb
Uphawu
AUO
Ubungakanani
3.0
Isicelo
DSC
Isigqibo
320×240
Ukuqamba
LCM
Ukuqaqamba
350
CR
300:1
Imibala
16.7M
Isibane ngasemva
WLED
Ujongano
Serial RGB
In Stock
6550
Iinkcukacha

Inombolo yendawo A030DN01 VC
UphawuAUO
Ubungakanani3.0
IsiceloDSC
Isigqibo320×240
UkuqambaLCM
Ukuqaqamba350
CR300:1
Imibala16.7M
Isibane ngasemvaWLED
UjonganoSerial RGB
uphawu lwephaneliAUO
imodeli yephaneliA030DN01 VC
uhlobo lwephaneli a-Si TFT-LCD , LCM
ubungakanani bephaneli3.0 inch
isisombululo320(RGB)×240 , QVGA
imowudi yokubonisaTN, Normally White, Transmissive
indawo esebenzayo60×45 mm
ulwandlalo70.2×51.4 mm
umphezuluHard coating
ukuqaqamba350 cd/m² (Typ.)
umlinganiselo wokuchasana300:1 (Typ.)
bonisa imibala16.7M (8-bit)
ixesha lokuphendula10/25 (Typ.)(Tr/Td)
i-engile yokujonga60/60/50/60 (Typ.)(CR≥10)(L/R/U/D)
rhoqo60Hz
uhlobo lwesibane3S1PWLEDWithout Driver
ujongano lomqondisoSerial RGB (8-bit) + SPI, CCIR601/656, 39 pins
igalelo lombane3.3/15/-10V (Typ.)(VDD/VGH/VGL)
isiceloDSC
Umzekelo woSapho
A030DN01 V0 AUO 3.0 320×240
A030DN01 V9 AUO 3.0 320×240
A030DN01 VC AUO 3.0 320×240
A030DN04 V0 AUO 3.0 320×240
A030DN05 V0 AUO 3.0 320×240
A030DW01 V0 AUO 3.0 320×240
A030DW01 V1 AUO 3.0 320×240
A030DW01 V3 AUO 3.0 320×240
LQ030Q3DG01 SHARP 3.0 320×240
TM030ZDHG01 Tianma 3.0 320×320
